Gruppo di prodotti 15289016

Rahmenschrauben Flachkopf-FK 13,5 mm und I-Stern I30 für Alu-, Holz- & PVC-Profile

Superficie	001 galvanized
Ex WGR n.:	6515

Produktfilter

size

Alle 7,5X52 7,5X72 7,5X82 7,5X92 7,5X112 7,5X132 7,5X152 7,5X182 7,5X212 7,5X252 7,5X302

nominal length

Alle 52.0 mm 72.0 mm 82.0 mm 92.0 mm 112.0 mm 132.0 mm 152.0 mm 182.0 mm 212.0 mm 252.0 mm 302.0 mm

Numero di materiale	thread diameter	size	drive size	drive type-fastener	thread type	Imballaggio
10045359	7.5 mm	7,5X52	hexalobe 30	hexalobe	wall thread	STD 100
10045359	7.5 mm	7,5X52	hexalobe 30	hexalobe	wall thread	STD 100
10045351	7.5 mm	7,5X52	hexalobe 30	hexalobe	wall thread	STD 100
10045355	7.5 mm	7,5X52	hexalobe 30	hexalobe	wall thread	STD 1400
10045371	7.5 mm	7,5X72	hexalobe 30	hexalobe	wall thread	STD 100
10045371	7.5 mm	7,5X72	hexalobe 30	hexalobe	wall thread	STD 100
10045363	7.5 mm	7,5X72	hexalobe 30	hexalobe	wall thread	STD 100
10045367	7.5 mm	7,5X72	hexalobe 30	hexalobe	wall thread	STD 1000
10180363	7.5 mm	7,5X82	hexalobe 30	hexalobe	wall thread	STD 100
10045385	7.5 mm	7,5X92	hexalobe 30	hexalobe	wall thread	STD 100
10045385	7.5 mm	7,5X92	hexalobe 30	hexalobe	wall thread	STD 100
10045376	7.5 mm	7,5X92	hexalobe 30	hexalobe	wall thread	STD 100
10045381	7.5 mm	7,5X92	hexalobe 30	hexalobe	wall thread	STD 1000
10045398	7.5 mm	7,5X112	hexalobe 30	hexalobe	wall thread	STD 100
10045398	7.5 mm	7,5X112	hexalobe 30	hexalobe	wall thread	STD 100
10045389	7.5 mm	7,5X112	hexalobe 30	hexalobe	wall thread	STD 100
10045393	7.5 mm	7,5X112	hexalobe 30	hexalobe	wall thread	STD 600
10045412	7.5 mm	7,5X132	hexalobe 30	hexalobe	wall thread	STD 100
10045412	7.5 mm	7,5X132	hexalobe 30	hexalobe	wall thread	STD 100
10045403	7.5 mm	7,5X132	hexalobe 30	hexalobe	wall thread	STD 100
10045407	7.5 mm	7,5X132	hexalobe 30	hexalobe	wall thread	STD 550
10045427	7.5 mm	7,5X152	hexalobe 30	hexalobe	wall thread	STD 100
10045427	7.5 mm	7,5X152	hexalobe 30	hexalobe	wall thread	STD 100
10045417	7.5 mm	7,5X152	hexalobe 30	hexalobe	wall thread	STD 100
10045422	7.5 mm	7,5X152	hexalobe 30	hexalobe	wall thread	STD 450
10045441	7.5 mm	7,5X182	hexalobe 30	hexalobe	wall thread	STD 100
10045441	7.5 mm	7,5X182	hexalobe 30	hexalobe	wall thread	STD 100
10045432	7.5 mm	7,5X182	hexalobe 30	hexalobe	wall thread	STD 100
10045436	7.5 mm	7,5X182	hexalobe 30	hexalobe	wall thread	STD 400
10045451	7.5 mm	7,5X212	hexalobe 30	hexalobe	wall thread	STD 0
10045451	7.5 mm	7,5X212	hexalobe 30	hexalobe	wall thread	STD 0
10045455	7.5 mm	7,5X212	hexalobe 30	hexalobe	wall thread	STD 0
10045445	7.5 mm	7,5X212	hexalobe 30	hexalobe	wall thread	STD 100
10045465	7.5 mm	7,5X252	hexalobe 30	hexalobe	wall thread	STD 0
10045465	7.5 mm	7,5X252	hexalobe 30	hexalobe	wall thread	STD 0
10045461	7.5 mm	7,5X252	hexalobe 30	hexalobe	wall thread	STD 0
10045470	7.5 mm	7,5X302	hexalobe 30	hexalobe	wall thread	STD 0
10045470	7.5 mm	7,5X302	hexalobe 30	hexalobe	wall thread	STD 0
10045475	7.5 mm	7,5X302	hexalobe 30	hexalobe	wall thread	STD 0
