Product group 15337023

LISEKO SHR w.SZ DIN 964

Norm:	DIN 964, DIN ISO 2010
Surface	001 galvanized
Former WGR no.:	0430

Produktfilter

Material number	thread diameter	size	drive size	strength class-fastener	drive type-fastener	Packaging
10090204	3.0 mm	M3X5	0,8 mm	4.8	slot	STD 2000
10090220	3.0 mm	M3X6	0,8 mm	4.8	slot	STD 100
10090220	3.0 mm	M3X6	0,8 mm	4.8	slot	STD 100
10090212	3.0 mm	M3X6	0,8 mm	4.8	slot	STD 2000
10090238	3.0 mm	M3X8	0,8 mm	4.8	slot	STD 100
10090238	3.0 mm	M3X8	0,8 mm	4.8	slot	STD 100
10090229	3.0 mm	M3X8	0,8 mm	4.8	slot	STD 2000
10090256	3.0 mm	M3X10	0,8 mm	4.8	slot	STD 100
10090256	3.0 mm	M3X10	0,8 mm	4.8	slot	STD 100
10090246	3.0 mm	M3X10	0,8 mm	4.8	slot	STD 2000
10090272	3.0 mm	M3X12	0,8 mm	4.8	slot	STD 100
10090272	3.0 mm	M3X12	0,8 mm	4.8	slot	STD 100
10090262	3.0 mm	M3X12	0,8 mm	4.8	slot	STD 2000
10090289	3.0 mm	M3X16	0,8 mm	4.8	slot	STD 100
10090289	3.0 mm	M3X16	0,8 mm	4.8	slot	STD 100
10090281	3.0 mm	M3X16	0,8 mm	4.8	slot	STD 2000
10090309	3.0 mm	M3X20	0,8 mm	4.8	slot	STD 100
10090309	3.0 mm	M3X20	0,8 mm	4.8	slot	STD 100
10090300	3.0 mm	M3X20	0,8 mm	4.8	slot	STD 2000
10090327	3.0 mm	M3X25	0,8 mm	4.8	slot	STD 100
10090327	3.0 mm	M3X25	0,8 mm	4.8	slot	STD 100
10090318	3.0 mm	M3X25	0,8 mm	4.8	slot	STD 2000
10090345	3.0 mm	M3X30	0,8 mm	4.8	slot	STD 100
10090345	3.0 mm	M3X30	0,8 mm	4.8	slot	STD 100
10090336	3.0 mm	M3X30	0,8 mm	4.8	slot	STD 2000
10090354	3.0 mm	M3X35	0,8 mm	4.8	slot	STD 1000
10090363	3.0 mm	M3X40	0,8 mm	4.8	slot	STD 100
10090372	3.0 mm	M3X50	0,8 mm	4.8	slot	STD 1
10090388	4.0 mm	M4X6	Bit size 1	4.8	slot	STD 100
10090388	4.0 mm	M4X6	Bit size 1	4.8	slot	STD 100
10090381	4.0 mm	M4X6	Bit size 1	4.8	slot	STD 2000
10090406	4.0 mm	M4X8	Bit size 1	4.8	slot	STD 100
10090406	4.0 mm	M4X8	Bit size 1	4.8	slot	STD 100
10090397	4.0 mm	M4X8	Bit size 1	4.8	slot	STD 2000
10090422	4.0 mm	M4X10	Bit size 1	4.8	slot	STD 100
10090422	4.0 mm	M4X10	Bit size 1	4.8	slot	STD 100
10090414	4.0 mm	M4X10	Bit size 1	4.8	slot	STD 2000
10090438	4.0 mm	M4X12	Bit size 1	4.8	slot	STD 100
10090438	4.0 mm	M4X12	Bit size 1	4.8	slot	STD 100
10090430	4.0 mm	M4X12	Bit size 1	4.8	slot	STD 2000
10090454	4.0 mm	M4X16	Bit size 1	4.8	slot	STD 100
10090454	4.0 mm	M4X16	Bit size 1	4.8	slot	STD 100
10090446	4.0 mm	M4X16	Bit size 1	4.8	slot	STD 2000
10090470	4.0 mm	M4X20	Bit size 1	4.8	slot	STD 100
10090470	4.0 mm	M4X20	Bit size 1	4.8	slot	STD 100
10090461	4.0 mm	M4X20	Bit size 1	4.8	slot	STD 2000
10090488	4.0 mm	M4X25	Bit size 1	4.8	slot	STD 100
10090488	4.0 mm	M4X25	Bit size 1	4.8	slot	STD 100
10090479	4.0 mm	M4X25	Bit size 1	4.8	slot	STD 1000
10090503	4.0 mm	M4X30	Bit size 1	4.8	slot	STD 100
10090503	4.0 mm	M4X30	Bit size 1	4.8	slot	STD 100
10090496	4.0 mm	M4X30	Bit size 1	4.8	slot	STD 1000
10090519	4.0 mm	M4X35	Bit size 1	4.8	slot	STD 100
10090519	4.0 mm	M4X35	Bit size 1	4.8	slot	STD 100
10090511	4.0 mm	M4X35	Bit size 1	4.8	slot	STD 1000
10090527	4.0 mm	M4X40	Bit size 1	4.8	slot	STD 1000
10090536	4.0 mm	M4X45	Bit size 1	4.8	slot	STD 1000
10090544	4.0 mm	M4X50	Bit size 1	4.8	slot	STD 1000
10090554	4.0 mm	M4X55	Bit size 1	4.8	slot	STD 200
10090562	4.0 mm	M4X60	Bit size 1	4.8	slot	STD 200
10090571	4.0 mm	M4X65	Bit size 1	4.8	slot	STD 200
10090580	4.0 mm	M4X70	Bit size 1	4.8	slot	STD 200
10090590	4.0 mm	M4X80	Bit size 1	4.8	slot	STD 200
10090608	5.0 mm	M5X8	1,2 mm	4.8	slot	STD 100
10090608	5.0 mm	M5X8	1,2 mm	4.8	slot	STD 100
10090599	5.0 mm	M5X8	1,2 mm	4.8	slot	STD 2000
10090626	5.0 mm	M5X10	1,2 mm	4.8	slot	STD 100
10090626	5.0 mm	M5X10	1,2 mm	4.8	slot	STD 100
10090617	5.0 mm	M5X10	1,2 mm	4.8	slot	STD 2000
10090644	5.0 mm	M5X12	1,2 mm	4.8	slot	STD 100
10090644	5.0 mm	M5X12	1,2 mm	4.8	slot	STD 100
10090634	5.0 mm	M5X12	1,2 mm	4.8	slot	STD 1000
10090661	5.0 mm	M5X16	1,2 mm	4.8	slot	STD 100
10090661	5.0 mm	M5X16	1,2 mm	4.8	slot	STD 100
10090653	5.0 mm	M5X16	1,2 mm	4.8	slot	STD 1000
10195985	5.0 mm	M5X18	1,2 mm	4.8	slot	STD 1000
10090679	5.0 mm	M5X20	1,2 mm	4.8	slot	STD 100
10090679	5.0 mm	M5X20	1,2 mm	4.8	slot	STD 100
10090670	5.0 mm	M5X20	1,2 mm	4.8	slot	STD 1000
10090696	5.0 mm	M5X25	1,2 mm	4.8	slot	STD 100
10090696	5.0 mm	M5X25	1,2 mm	4.8	slot	STD 100
10090688	5.0 mm	M5X25	1,2 mm	4.8	slot	STD 1000
10090716	5.0 mm	M5X30	1,2 mm	4.8	slot	STD 100
10090716	5.0 mm	M5X30	1,2 mm	4.8	slot	STD 100
10090705	5.0 mm	M5X30	1,2 mm	4.8	slot	STD 1000
10090735	5.0 mm	M5X35	1,2 mm	4.8	slot	STD 100
10090735	5.0 mm	M5X35	1,2 mm	4.8	slot	STD 100
10090726	5.0 mm	M5X35	1,2 mm	4.8	slot	STD 500
10090752	5.0 mm	M5X40	1,2 mm	4.8	slot	STD 100
10090752	5.0 mm	M5X40	1,2 mm	4.8	slot	STD 100
10090744	5.0 mm	M5X40	1,2 mm	4.8	slot	STD 500
10090761	5.0 mm	M5X45	1,2 mm	4.8	slot	STD 500
10090778	5.0 mm	M5X50	1,2 mm	4.8	slot	STD 100
10090778	5.0 mm	M5X50	1,2 mm	4.8	slot	STD 100
10090770	5.0 mm	M5X50	1,2 mm	4.8	slot	STD 500
10090787	5.0 mm	M5X55	1,2 mm	4.8	slot	STD 200
10090805	5.0 mm	M5X60	1,2 mm	4.8	slot	STD 50
10090805	5.0 mm	M5X60	1,2 mm	4.8	slot	STD 50
10090795	5.0 mm	M5X60	1,2 mm	4.8	slot	STD 200
10090815	5.0 mm	M5X65	1,2 mm	4.8	slot	STD 200
10090834	5.0 mm	M5X70	1,2 mm	4.8	slot	STD 50
10090834	5.0 mm	M5X70	1,2 mm	4.8	slot	STD 50
10090824	5.0 mm	M5X70	1,2 mm	4.8	slot	STD 200
10090852	5.0 mm	M5X80	1,2 mm	4.8	slot	STD 50
10090852	5.0 mm	M5X80	1,2 mm	4.8	slot	STD 50
10090843	5.0 mm	M5X80	1,2 mm	4.8	slot	STD 200
10090861	5.0 mm	M5X90	1,2 mm	4.8	slot	STD 200
10090870	5.0 mm	M5X100	1,2 mm	4.8	slot	STD 200
10090879	6.0 mm	M6X8	1,6 mm	4.8	slot	STD 1000
10090898	6.0 mm	M6X10	1,6 mm	4.8	slot	STD 100
10090898	6.0 mm	M6X10	1,6 mm	4.8	slot	STD 100
10090888	6.0 mm	M6X10	1,6 mm	4.8	slot	STD 1000
10090915	6.0 mm	M6X12	1,6 mm	4.8	slot	STD 100
10090915	6.0 mm	M6X12	1,6 mm	4.8	slot	STD 100
10090906	6.0 mm	M6X12	1,6 mm	4.8	slot	STD 1000
10090933	6.0 mm	M6X16	1,6 mm	4.8	slot	STD 100
10090933	6.0 mm	M6X16	1,6 mm	4.8	slot	STD 100
10090925	6.0 mm	M6X16	1,6 mm	4.8	slot	STD 1000
10090951	6.0 mm	M6X20	1,6 mm	4.8	slot	STD 100
10090951	6.0 mm	M6X20	1,6 mm	4.8	slot	STD 100
10090941	6.0 mm	M6X20	1,6 mm	4.8	slot	STD 1000
10090969	6.0 mm	M6X25	1,6 mm	4.8	slot	STD 100
10090969	6.0 mm	M6X25	1,6 mm	4.8	slot	STD 100
10090959	6.0 mm	M6X25	1,6 mm	4.8	slot	STD 500
10090988	6.0 mm	M6X30	1,6 mm	4.8	slot	STD 100
10090988	6.0 mm	M6X30	1,6 mm	4.8	slot	STD 100
10090979	6.0 mm	M6X30	1,6 mm	4.8	slot	STD 500
10091008	6.0 mm	M6X35	1,6 mm	4.8	slot	STD 100
10091008	6.0 mm	M6X35	1,6 mm	4.8	slot	STD 100
10090998	6.0 mm	M6X35	1,6 mm	4.8	slot	STD 500
10091026	6.0 mm	M6X40	1,6 mm	4.8	slot	STD 100
10091026	6.0 mm	M6X40	1,6 mm	4.8	slot	STD 100
10091017	6.0 mm	M6X40	1,6 mm	4.8	slot	STD 500
10091044	6.0 mm	M6X45	1,6 mm	4.8	slot	STD 50
10091044	6.0 mm	M6X45	1,6 mm	4.8	slot	STD 50
10091034	6.0 mm	M6X45	1,6 mm	4.8	slot	STD 200
10091062	6.0 mm	M6X50	1,6 mm	4.8	slot	STD 50
10091062	6.0 mm	M6X50	1,6 mm	4.8	slot	STD 50
10091053	6.0 mm	M6X50	1,6 mm	4.8	slot	STD 200
10091084	6.0 mm	M6X55	1,6 mm	4.8	slot	STD 50
10091084	6.0 mm	M6X55	1,6 mm	4.8	slot	STD 50
10091073	6.0 mm	M6X55	1,6 mm	4.8	slot	STD 200
10091102	6.0 mm	M6X60	1,6 mm	4.8	slot	STD 50
10091102	6.0 mm	M6X60	1,6 mm	4.8	slot	STD 50
10091092	6.0 mm	M6X60	1,6 mm	4.8	slot	STD 200
10091111	6.0 mm	M6X65	1,6 mm	4.8	slot	STD 200
10091131	6.0 mm	M6X70	1,6 mm	4.8	slot	STD 25
10091131	6.0 mm	M6X70	1,6 mm	4.8	slot	STD 25
10091120	6.0 mm	M6X70	1,6 mm	4.8	slot	STD 200
10091140	6.0 mm	M6X80	1,6 mm	4.8	slot	STD 200
10091151	6.0 mm	M6X90	1,6 mm	4.8	slot	STD 100
10091160	6.0 mm	M6X100	1,6 mm	4.8	slot	STD 100
10091169	8.0 mm	M8X12	Bit size 2	4.8	slot	STD 500
10091189	8.0 mm	M8X16	Bit size 2	4.8	slot	STD 100
10091189	8.0 mm	M8X16	Bit size 2	4.8	slot	STD 100
10091179	8.0 mm	M8X16	Bit size 2	4.8	slot	STD 500
10091207	8.0 mm	M8X20	Bit size 2	4.8	slot	STD 100
10091207	8.0 mm	M8X20	Bit size 2	4.8	slot	STD 100
10091197	8.0 mm	M8X20	Bit size 2	4.8	slot	STD 500
10091225	8.0 mm	M8X25	Bit size 2	4.8	slot	STD 50
10091225	8.0 mm	M8X25	Bit size 2	4.8	slot	STD 50
10091216	8.0 mm	M8X25	Bit size 2	4.8	slot	STD 500
10091241	8.0 mm	M8X30	Bit size 2	4.8	slot	STD 50
10091241	8.0 mm	M8X30	Bit size 2	4.8	slot	STD 50
10091233	8.0 mm	M8X30	Bit size 2	4.8	slot	STD 200
10091251	8.0 mm	M8X35	Bit size 2	4.8	slot	STD 200
10091269	8.0 mm	M8X40	Bit size 2	4.8	slot	STD 50
10091269	8.0 mm	M8X40	Bit size 2	4.8	slot	STD 50
10091260	8.0 mm	M8X40	Bit size 2	4.8	slot	STD 100
10091291	8.0 mm	M8X45	Bit size 2	4.8	slot	STD 50
10091291	8.0 mm	M8X45	Bit size 2	4.8	slot	STD 50
10091280	8.0 mm	M8X45	Bit size 2	4.8	slot	STD 100
10091300	8.0 mm	M8X50	Bit size 2	4.8	slot	STD 100
10091310	8.0 mm	M8X55	Bit size 2	4.8	slot	STD 100
10091321	8.0 mm	M8X60	Bit size 2	4.8	slot	STD 100
10091332	8.0 mm	M8X70	Bit size 2	4.8	slot	STD 100
10091341	8.0 mm	M8X80	Bit size 2	4.8	slot	STD 100
10091350	8.0 mm	M8X100	Bit size 2	4.8	slot	STD 100
10091359	10.0 mm	M10X20	2,5 mm	4.8	slot	STD 100
10091368	10.0 mm	M10X25	2,5 mm	4.8	slot	STD 200
10091378	10.0 mm	M10X30	2,5 mm	4.8	slot	STD 200
10091387	10.0 mm	M10X35	2,5 mm	4.8	slot	STD 100
10091395	10.0 mm	M10X40	2,5 mm	4.8	slot	STD 100
10091404	10.0 mm	M10X45	2,5 mm	4.8	slot	STD 100
10091413	10.0 mm	M10X50	2,5 mm	4.8	slot	STD 100
10091423	10.0 mm	M10X60	2,5 mm	4.8	slot	STD 100
10091433	10.0 mm	M10X70	2,5 mm	4.8	slot	STD 100
10091442	10.0 mm	M10X80	2,5 mm	4.8	slot	STD 100
